Z51100 Vertical Drilling Machine
from /month
MACHINE description
|
Specifications |
Z51100 |
|
Max drilling dia. |
100mm |
|
Max feed resistance |
45000N |
|
Max. spindle allowable torque |
1150N.m |
|
Spindle taper |
MorseNO.6 |
|
Distance from spindle axis to column guideway |
480mm |
|
Spindle travel |
310mm |
|
Spindle box travel |
300mm |
|
Spindle speedrange(steps) |
26-320r/min(6) |
|
The amount of feed(mm/rev) |
0.096-0.717r/min(6) |
|
Working table stroke |
300mm |
|
Working table surface size |
760×650mm |
|
Distancefromspindlenosetotablesurface |
850mm |
|
Main motor power |
7.5kw |
|
Cooling pump flow |
25L/min |
|
Overall dimension |
1465×970×3170mm |
|
N/W |
3500kg |
