GH4240 Band Saw Machine
  • GH4240 Band Saw Machine

GH4240 Band Saw Machine

Get a special offer

    MACHINE description

    Model Units GH4240
    Cutting capability Circular mm 400
      Rectangular mm 400x400
    Blade speed m/min 27、45、69
    Blade size mm 5000*41*1.3
    Main motor power kw 4
    Hydraulic motor power kw 0.75
    Coolant pump（w） w 90
    Work clamping method - Hydraulic vise
    Machine weight kg 1500
    Overall dimension mm 2520*1200*2000
    Package Size mm 2580*1270*2100

    Application：

    For high precision metal cutting, is the ideal equipment for the industrial and mining enterprises and small workshops, use is very extensive.

    CHARACTERISTICS

    The main performance characteristics：

    1. Double upright column machine type ,rigidity good stability.
    2. Hand wave feeding mechanism, sawing automatic cycle.
    3. Feeding stepless speed change, Saw belt stepless speed change
    4. The size of the positioning device, For batch production.
