GH4265 Band Saw Machine
  • GH4265 Band Saw Machine

GH4265 Band Saw Machine

Get a special offer

    MACHINE description

    Model Units GH4265
    Cutting capability Circular mm 650
      Rectangular mm 650x650
    Blade speed m/min 27、45、69
    Blade size mm 7024*54*1.6
    Main motor power kw 7.5
    Hydraulic motor power kw 1.5
    Coolant pump（w） w 125
    Work clamping method - Hydraulic vise
    Machine weight kg 4000
    Overall dimension mm 3200*1380*2200
    Package Size mm 3350*1500*2450

    1. Extra rigid saw frame design ensures excellent angular accuracy and low vibration when cutting workpieces with very large diameters;
    2. The material support surface features driven feed rollers with extremely high-load capacity ,suitable for very heavy workpiece;
    3. Saw frame lifting adopted double oil cylinder control ,ensuring smooth working;
    4. The heavy saw blade tensioning reduces the workload and helps prevent inaccuracies and premature wear of the saw blade;
    5. One bi-metallic band saw blade and feed roller table are included
