X6128 Horizontal Milling Machine

Specifications

Units

X6128

Table size

mm

1200×280

Table travel

mm

680/280/400

T slot(number-width-pitch)

mm

5-14-50

Spindle taper

-

IS0407:24

Spindle speed range

rpm

40-1300 (12 steps)

Distance between spindle axis and table surface

mm

0-400

Main motor power

kw

3

Weight

kg

1300

Overall dimension

mm

1725×1450×1750
