• GHZ4260 Rotary Band Saw Machine

GHZ4260 Rotary Band Saw Machine

Get a special offer

    MACHINE description

    Specifications GHZ4260
    Cutting capacity 90° Rectangular 600×600mm
    Circular 500mm
    Cutting capacity 45° Rectangular 600x520mm
    Circular -
    Cutting capacity 30° Rectangular 600x425mm
    Circular 425mm
    Saw blade speed 27\45\69m/min
    Belt saw blade size 6500x41x1.3
    Motor power Main motor 5.5kw
    Oil pump motor 0.75kw
    Cooling pump motor 0.09kw
    Overall dimension 3300x1800x2200mm

    CHARACTERISTICS

    1.  Extremely rigid dual-column cast-iron construction with heavy swivel console
    2. Three cutting speeds-directly shifted via main drive motor infinitely variable saw frame feed
    3. Horizontal saw frame swivels up to 45 °
    4. Saw frame automatically returns to home position at the end of each cut extra rigid, adjustable saw blade guide including hydraulic workpiece clamping with clamping pressure control
    5. Standard equipment: hydraulic workpiece clamping, 1 saw blade belt, material support stand, coolant system, work lamp, operation manual
    6. Optional equipment: automatic blade breakage control, fast drop protection devise, hydraulic blade tension, automatic chip removal device, various blade linear speed, blade protection covers, wheel cover opening protection, Ce standard electrical equipment
