- Solid steel saw frame within a dual-column frame guide
- Flat and low profile for easier handling of heavy or large workpiece
- Feed of the saw frame is infinitely variable via a hydraulic throttle valve
- Adjustable saw blade guide ensures good cutting result at any workpiecediameter
- Hydraulic workpiece clamping included
GH4260 Band Saw Machine
MACHINE description
| Model | Units | GH4260 | |
| Cutting capability | Circular | mm | 600 |
| Rectangular | mm | 600x600 | |
| Blade speed | m/min | 27、45、69 | |
| Blade size | mm | 6630*54*1.6 | |
| Main motor power | kw | 5.5 | |
| Hydraulic motor power | kw | 1.5 | |
| Coolant pump（w） | w | 125 | |
| Work clamping method | - | Hydraulic vise | |
| Machine weight | kg | 3200 | |
| Overall dimension | mm | 3150*1350*2200 | |
| Package Size | mm | 3300*1450*2400 | |
