GHZ4240 Rotary Band Saw Machine
MACHINE description
| Model | Units | GHZ4240 | |
| Cutting capability | 0° | mm | 550x400 |
| 45° | mm | 300x400 | |
| Blade speed | m/min | 27、45、69 | |
| Blade size | mm | 5400*41*1.3 | |
| Main motor power | kw | 4 | |
| Hydraulic motor power | kw | 1.5 | |
| Coolant pump（w） | w | 125 | |
| Work clamping method | - | Hydraulic vise | |
| Machine weight | kg | 1600 | |
| Overall dimension | mm | 2400*1800*1850 | |
| Package Size | mm | 2460*1950*2000 | |
