Application：
For high precision metal cutting, is the ideal equipment for the industrial and mining enterprises and small workshops, use is very extensive.
GH4220 Band Saw Machine
MACHINE description
Model |
Units |
GH4220 |
|
Cutting capability |
Circular |
mm |
200 |
Rectangular |
mm |
200x200 |
|
Blade speed |
m/min |
27、45、69 |
|
Blade size |
mm |
2800*27*0.9 |
|
Main motor power |
kw |
1.5 |
|
Hydraulic motor power |
kw |
0.55 |
|
Coolant pump（w） |
w |
40 |
|
Work clamping method |
- |
Hydraulic vise |
|
Machine weight |
kg |
600 |
|
Overall dimension |
mm |
1350*900*1200 |
|
Package Size |
mm |
1460*930*1270 |
|
CHARACTERISTICS
The main performance characteristics：
- Saw frame travels across solid dual-column guides
- Rigid, adjustable saw blade guides prevent lateral escape of the saw blade and ensure maximum angular accuracy
- Ideally positioned control panel within comfortable reach on top of the saw frame
- At the end of each sawing cycle, the saw blade frame will automatically return to the home position
- Tthrottle valve allows infinitely variable saw frame feed
- Two cutting speeds for a wide spectrum of materials and workpiece diameters
- Manually adjustable workpiece clamping and linear stop
- Coolant system
