CA6150 CA6250 Lathe Machine

SPECIFICATIONS	Units	CA6150 CA6150B CA6150C	CA6250 CA6250B CA6250C
Swing over bed	mm	500
Swing over cross slide	mm	300
Swing over gap	mm	-	720
Gap length	mm	-	210
Distance between centers	mm	750/1000/1500/2000/2200/3000/4000
Spindle bore	mm	52 B:80 C:105
Spindle bore taper	-	MT6 B:90 1:20 C:113 1:20
Spindle speed range	rpm	10-1400/16-1400
Spindle speed steps	-	24
Cross slide travel	mm	320
Top tool post travel		140
Tool size		25*25
Longitudinal feeds kinds	kinds	64
Longitudinal feeds range	mm/r	0.028-6.33
Cross feeds range kinds	kinds	64
Cross feeds range	mm/r	0.014-3.16
Longitudinal fast moving	m/min	4
Cross fast moving	m/min	2
Kinds of metric threads	kinds	44
Range of metric threads	mm	1-192
Kinds of inch threads	kinds	21
Range of inch threads	T.P.I.	2-24
Kinds of module threads	kinds	39
Range of module threads	M.P.	0.25-48
Kinds of diametral threads hreads	kinds	37
Range of diametral threads hreads	D.P.	1-96
Tailstock quill diameter	mm	75
Tailstock quill taper	-	MT5
Tailstock quill travel	mm	150
Main motor power	kw	7.5
Coolant motor power	kw	0.09
Weight for 750	kg	2100
Weight for 1000	kg	2200
Weight for 1500	kg	2400
Weight for 2000	kg	2700
Weight for 3000	kg	3500
Weight for 4000	kg	4000
Dimension for 750	mm	244011501700
Dimension for 1000	mm	265011501700
Dimension for 1500	mm	315011501700
Dimension for 2000	mm	365011501700
Dimension for 3000	mm	480011501700
Dimension for 4000	mm	568011501700

CA series ordinary horizontal lathe is used to turning internal and external cylindrical surface, conical surface, and other rotating surface, turning various metric and inch, modulus and pitch thread, and the pitch diameter of the thread and pull the drilling and oil tank etc., is general very strong horizontal lathe, Widely applicable batch processing of various shaft and disc parts.
The series lathe bed width in general lathe, 400mm rail width has higher stiffness, rail surface by intermediate frequency quenching, wear-resistant durable.
Handy machine operator concentration, slide plate is provided with a quick moving mechanism. Using single handle operation, humanization.
The rigidity of the machine tool structure and the transmission stiffness are higher than the general lathe, the power utilization rate is high, which is suitable for the strong cutting.
Before leaving the machine tool factory, the machine tool is tested strictly according to the inspection procedure, and the machine tool is tested to ensure that the machine tool has good stability and reliability.

CHARACTERISTICS

Machine tool head box and bed, tailstock, Supporting plate, etc. the combination of surface between manual scraping, machine to undergo a rigorous inspection, effectively ensure the machine tool accuracy and stability.
Machine adopts high strength cast iron, copper and chromium special materials are added, the bed width 400mm, bed rail quenching depth up to 4mm, effectively improves the agreeability and stability of the machine.
The machine tool bed head box lubrication uses the pump to carry on the circulation forced lubrication, in view of the south hot weather, has guaranteed the bed head box cleanliness and the heat radiation characteristic, has effectively extended the bearing and gear’s service life.
Wafangdian Bearing is used in machine tool spindle, the spindle through hole diameter 80mm, machine tool gear with precision grinding, can effectively improve the hardness of the gears, to reduce noise of the machine.
Machine tool uses the domestic brand lead screw, the silk mother uses the high quality bronze alloy to guarantee the wear-resisting property and the precision maintenance.
The machine adopts high strength four station turret shank size: 25x25mm.
