Z5163 Vertical Drilling Machine
from /month
MACHINE description
|
Specifications |
Z5163 |
|
Max drilling diameter |
63mm |
|
Max feed resistance |
30000N |
|
Max. spindle allowable torque |
800N.m |
|
Spindle taper |
MorseNO.5 |
|
Distance from spindle axis to column guideway |
375mm |
|
Spindle travel |
250mm |
|
Spindle box travel |
250mm |
|
Spindle speed |
40-570r/min9steps |
|
The amount of feed(mm/rev) |
0.1-0.78r/min6steps |
|
Working table stroke |
300mm |
|
Working table surface size |
650×550mm |
|
Distancefromspindlenosetotablesurface |
800mm |
|
Main motor power |
5.5kw |
|
Cooling pump flow |
25L/min |
|
Overall dimension |
1452×965×2787mm |
|
N/W |
2800kg |
