X5028 Vertical Milling Machine
MACHINE description
|
Specifications |
Units |
X5028 |
|
Table size |
mm |
1200×280 |
|
Table travel |
mm |
650/320/350 |
|
T slot(number-width-pitch) |
mm |
3-14-50 |
|
Spindle taper |
ISO40 7:24 |
|
|
Spindle speed range |
rpm |
40-1300(12steps) |
|
Distance between spindle nose and table surface |
mm |
50-400 |
|
Distancebetweenspindleaxisto column surface |
mm |
320 |
|
Mainmotor power |
kw |
3 |
|
Weight |
kg |
1500 |
|
Overall dimension |
mm |
1700×1700×1850 |
