VTC650 CNC Vertical Lathe Machine
MACHINE description
|
Specification |
units |
VTC650 |
|
Max. Swing diameter |
mm |
650 |
|
Max. Turning diameter |
mm |
550 |
|
Spindle model |
A2-8 |
|
|
Diameter of spindle bearing |
mm |
120 |
|
Spindle speed range |
rpm |
50-1250 |
|
Spindle output torque |
nm |
475 |
|
Chuck diameter |
〞 |
15〞HYD |
|
Turret |
Hor.8 position |
|
|
Turret spec |
100 |
|
|
Tool size |
mm |
□25/φ40 |
|
Turret travel X axis |
mm |
-375 |
|
Turret travel Z axis |
mm |
550 |
|
Distance from bottom of turret to up of chuck |
mm |
0-550 |
|
X/Z linear rails |
45 roller |
|
|
Diameter of X/Z screw |
mm |
φ40 |
|
X axis rapid traverse |
m/min |
15 |
|
Zaxis rapid traverse |
m/min |
12 |
|
Cutting feed |
m/min |
0.1-5000 |
|
X axis motor power/torque |
Kw/nm |
2.4/15 |
|
Zaxis motor power/torque |
Kw/nm |
2.4/15 |
|
Main motor power/torque |
Kw/nm |
15/18.5- 190 |
|
Overall size (L*W*H) |
m |
1.95x1.85x2.65 |
|
Machine weight |
kg |
5200 |
