| SPECIFICATIONS | Units | VMC850 |
| Table size | mm | 1000*500 |
| X axis travel | mm | 800 |
| Y axis travel | mm | 500 |
| Z axis travel | mm | 500 |
| Max. worktable load | kg | 500 |
| T slot(number-width*pitch) | - | 5-18*100 |
| Max. spindle speed | rpm | 8000 |
| Spindle taper | BT | BT40 |
| Main motor power | kw | 7.5 |
| X/Y/Z rapid traverse speed | m/min | 24/24/20 |
| Cutting feed speed | mm/min | 1-8000 |
| Guide rail type | - | Linear rail |
| Distance from spindle axis to column surface | mm | 525 |
| Distance between spindle nose and table surface | mm | 130-630 |
| Positioning accuracy | mm | ±0.0075 |
| Repeat positioning accuracy | mm | ±0.005 |
| Tool magazine | - | Arm 24 |
| Max. tool diameter | mm | 78/120 |
| Max. tool weight | kg | 8 |
| Machine weight | kg | 5500 |
| Overall dimension | mm | 2600*2300*2800 |
This VMC is suitable for mechanical processing and mold making .And it can asapt to the processing requirement from rough machining to finish machining .It can also finish many working procedures like milling ,drilling ,tapping ,boring ,etc.
