GHS4230 CNC Band Saw Machine
MACHINE description
| Model | Units | GHS4230 | |
| Cutting capability | Circular | mm | 300 |
| Rectangular | mm | 300x300 | |
| Blade speed | m/min | 27、45、69 | |
| Blade size | mm | 3505*27*0.9 | |
| Main motor power | kw | 3 | |
| Hydraulic motor power | kw | 0.75 | |
| Coolant pump（w） | w | 40 | |
| Work clamping method | - | Hydraulic automatic | |
| Machine weight | kg | 1400KG | |
| Overall dimension | mm | 1800*2350*1500 | |
| Package Size | mm | 2000*2450*1650 | |
