• GH4265 Band Saw Machine

GH4265 Band Saw Machine

from /month

MACHINE description

Model Units GH4265
Cutting capability Circular mm 650
  Rectangular mm 650x650
Blade speed m/min 27、45、69
Blade size mm 7024*54*1.6
Main motor power kw 7.5
Hydraulic motor power kw 1.5
Coolant pump(w) w 125
Work clamping method - Hydraulic vise
Machine weight kg 4000
Overall dimension mm 3200*1380*2200
Package Size mm 3350*1500*2450

  1. Extra rigid saw frame design ensures excellent angular accuracy and low vibration when cutting workpieces with very large diameters;
  2. The material support surface features driven feed rollers with extremely high-load capacity ,suitable for very heavy workpiece;
  3. Saw frame lifting adopted double oil cylinder control ,ensuring smooth working;
  4. The heavy saw blade tensioning reduces the workload and helps prevent inaccuracies and premature wear of the saw blade;
  5. One bi-metallic band saw blade and feed roller table are included
