GH42100 Band Saw Machine
  • GH42100 Band Saw Machine

GH42100 Band Saw Machine

Get a special offer

    MACHINE description

    Model Units GH42100
    Cutting capability Circular mm 1000
      Rectangular mm 1000x1000
    Blade speed m/min 27、45、69
    Blade size mm 9820*67*1.6
    Main motor power kw 11
    Hydraulic motor power kw 3.75
    Coolant pump（w） w 125
    Work clamping method - Hydraulic vise
    Machine weight kg 10000
    Overall dimension mm 4600*2000*2550 / 2300*450*700
    Package Size mm 4600*2000*2550 / 2300*450*700

    1. Extra rigid saw frame design ensures excellent angular accuracy and low vibration when cutting workpieces with very large diameters;
    2. The material support surface features driven feed rollers with extremely high-load capacity ,suitable for very heavy workpiece;
    3. Saw frame lifting adopted double oil cylinder control ,ensuring smooth working;
    4. The heavy saw blade tensioning reduces the workload and helps prevent inaccuracies and premature wear of the saw blade;
    5. One bi-metallic band saw blade and feed roller table are included

    CHARACTERISTICS

    The main performance characteristics：

    1.  Double upright column machine type ,rigidity good stability.
    2. Hand wave feeding mechanism, sawing automatic cycle.
    3. Feeding stepless speed change , Saw belt stepless speed change.
    4. The size of the positioning device,For batch production.
