C6241 Lathe Machine
MACHINE description
| Specification | C6241 |
| Swing over bed | 410mm(16") |
| Swing over cross slide | 220mm(8-13/16") |
| Swing in gap diameter | 640mm(25-1/8") |
| Distance between centers | 1000mm(40")/1500mm(60")/2000mm(80") |
| Valid length of gap | 165mm(6-1/2") |
| Width of bed | 300mm(11-13/16") |
| Spindle nose | D1-6 |
| Spindle bore | 58mm(2-1/4") |
| Taper of spindle bore | No.6 Morse |
| Range of spindle speed | 12 changes, 25~2000r/min |
| Compound rest travel | 128mm(5") |
| Cross slide travel | 285mm(11-1/4") |
| Max.section of tool | 25×25mm(1"×1") |
| Lead screw thread | 6mm or 4T.P.I. |
| Longitudinal feeds range | 42 kinds, 0.031～1.7mm/rev(0.0011"～0.0633"/rev) |
| Cross feeds range | 42 kinds, 0.014～0.784mm/rev(0.00033"～0.01837"/rev) |
| Threads metric pitches | 41 kinds, 0.1～14mm |
| Threads imperial pitches | 60 kinds, 2～112T.P.I. |
| Threads diametral pitches | 50 kinds, 4～112DP |
| Threads module pitches | 34 kinds, 0.1～7MP |
| Quill diameter | 60mm(2-5/16") |
| Quill travel | 130mm(5") |
| Quill taper | No.4 Morse |
| Main motor power | 5.5kW(7.5HP) 3PH |
| Coolant pump power | 0.1kW(1/8HP) 3PH |
| Overall dimension(L×W×H) | 220/275/325×108×134cm |
| Packing size(L×W×H) | 225/280/330×112×162cm |
| Net weight | 1580/1745/1900kg |
| Gross weight | 1845/2050/2230kg |
