YTU 400 (200×400) Horizontal Spindle Surface Grinding Machine

from $1 900/month

Get a special offer

    MACHINE description

    YTU 400 (200x400) Horizontal Spindle Surface Grinding Machine

    Manual Model

    • Cast iron body
    • ‘Y’ Axis automatic feeding
    • Movable(Portable) operation control panel
    • Electro Magnetic Table (200×400)
    • ‘X-Axis’ Hydraulic Table (Speed adjustable)
    • Time-setting automatic lubrication system for all slides and ball screws.
    • Transmission down and up movements with ball screw and automatic lubrication.
    • Ball screw system for table forward and backward with automatic lubrication.
    • Three different automatic grinding mode selection
    • Turcite coated slides
    • Grinding wheel main shaft and table axis with marble system
    • Cooling unit with fabric filter (Magnetic separator extra)
    • Movable work lighting lamp
    • Column curtain to secure the slides
    • Grinding wheel protector cover level adjustable’ (‘CE’Standards)
    • Front cabin protector cover curtains (‘CE’Standards)
    • Electric cabin secure system switches (‘CE’Standards)
    • Electric panel inside lighting lamp

    (NC) Automatic Model

    • Cast iron body
    • Z and Y Axis automatic feeding
    • Control panel with Touch screen and buttons
    • Movable(Portable) operation control panel
    • Electro Magnetic Table (200×400)
    • The electromagnetic table includes discharge magnetization
    • ‘X-Axis’ Hydraulic Table (Speed adjustable)
    • Grinding wheel (Speed adjustable 0-2800)
    • Easy programming and automatic surfacing process
    • Time-setting automatic lubrication system for all slides and ball screws.
    • Transmission down and up movements with ball screw and automatic lubrication.
    • Ball screw system for table forward and backward with automatic lubrication.
    • Three different automatic grinding mode selection
    • Turcite coated slides
    • Grinding wheel main shaft and table axis with marble system
    • Cooling unit with fabric filter (Magnetic separator extra)
    • Movable work lighting lamp
    • Wheel flat surface approaching led light
    • Column curtain for secure the slides
    • Grinding wheel protector cover level adjustable’ (‘CE’Standards)
    • Front cabin protector cover curtains (‘CE’Standards)
    • Electric cabin secure system switches (‘CE’Standards)
    • Electric panel inside lighting lamp
    Model

    YTU 400, YTU 400-NC
    Machine table surface ,mm

    500×200, 500×200
    Max. Grinding length(-X axis) , mm

    400, 400
    Max. Grinding width(-Y axis), mm

    200, 200
    Max.Distance from center of spindle to table, mm

    475, 475
    Max/Min. Table speed (-X axis), m/dk

    1-20, 1-20
    Automatic feed movement(-Y axis), mm

    0.1-40, 0.1-40
    Min.Manual feed movement (-Y axis), mm

    0.02, 0.02
    Automatic feed movement(-Z axis), mm

    0.01~0.02, 0.01~0.02
    Min.Manual feed movement (-Z axis), mm

    0.005, 0.005
    Grinding Wheel diameter(max), mm

    250x30x76.2, 250x30x76.2
    Grinding wheel rotation speed(speed adjustable for NC), rpm

    1400, 1400
    Electric system, V

    380 – 24, 380 – 24
    Stroke motor (Z),Kw

    0.37, 0.37
    Traverse motor (Y) ,Kw

    0.37, 0.37
    Hydraulic motor(X), Kw

    4, 4
    Spindle motor, Kw

    2.2, 2.2
    Automatic oiling pump motor, Kw

    0.18, 0.18
    Water pump motor, Kw

    0.37, 0.37
    Work length of machine ,mm

    1600, 1600
    Length of machine, mm

    1120, 1120
    Width of machine , mm

    1400, 1400
    Height of machine, mm

    1730, 1730
    Weight of machine, kg

    1450, 1450
    Manufacturer

    POLEKS

    Equipment

    YTU 400
    YTU 400 NC
    Standard/Extra Equipments
    Standard
    Extra
    Standard
    Extra
    Cooling Water Tank
    ●
    ●
    Hydraulic Tank
    ●
    ●
    Wheel Flange with Grinding Wheel(fixed on machine)
    ●
    ●
    Wheel Balancing Apparatus
    ●
    ●
    Wheel Disassembly Nuts
    ●
    ●
    Shaft of Wheel Balancing apparatus
    ●
    ●
    Water Protection Covers
    ●
    ●
    Magnetic Table
    ●
    ●
    Machine Balancing Components
    4
    4
    Wheel Dressing Apparatus
    ●
    ●
    1,5 Grad Wheel Grinding Diamond
    ●
    ●
    Users Manuel
    ●
    ●
    Electric Circuits
    ●
    ●
    Sliding Covers
    ●
    ●
    Magnetic Cooling Water Seperator
    ●
    ●
    Wheel Grinding Apparatus(on head)
    ●
    ●
    Parallels
    ●
    ●
    Hydraulic Tank with Cooling System
    ●
    ●
