VTC500 CNC Vertical Lathe Machine
from /month
MACHINE description
|
Specification |
units |
VTC500 |
|
Max. Swing diameter |
mm |
500 |
|
Max. Turning diameter |
mm |
400 |
|
Spindle model |
A2-8 |
|
|
Diameter of spindle bearing |
mm |
120 |
|
Spindle speed range |
rpm |
50-1250 |
|
Spindle output torque |
nm |
350 |
|
Chuck diameter |
〞 |
12〞HYD |
|
Turret |
Hor.8 position |
|
|
Turret spec |
100 |
|
|
Tool size |
mm |
□25/φ40 |
|
Turret travel X axis |
mm |
-325 |
|
Turret travel Z axis |
mm |
500 |
|
Distance from bottom of turret to up of chuck |
mm |
0-500 |
|
X/Z linear rails |
45 roller |
|
|
Diameter of X/Z screw |
mm |
φ40 |
|
X axis rapid traverse |
m/min |
15 |
|
Zaxis rapid traverse |
m/min |
12 |
|
Cutting feed |
m/min |
0.1-5000 |
|
X axis motor power/torque |
Kw/nm |
1.6/10 |
|
Zaxis motor power/torque |
Kw/nm |
2.4/15 |
|
Main motor power/torque |
Kw/nm |
11/15- 140 |
|
Overall size (L*W*H) |
m |
1.8x1.8x2.5 |
|
Machine weight |
kg |
4200 |
