CKQ6136 CNC Lathe Machine
from /month
MACHINE description
|
SPECIFICATIONS |
Units |
CQK6136 |
|
Swing over bed |
mm |
360 |
|
Swing over cross slide |
mm |
150 |
|
Distance between centers |
mm |
500/700 |
|
Spindle bore |
mm |
60 |
|
Spindle bore taper |
- |
MT6 |
|
Spindle nose type |
- |
A2-5 |
|
Spindle speed steps |
- |
Stepless |
|
Spindle speed range |
rpm |
100-2000 |
|
Tool size |
mm |
20*20 |
|
X axis travel |
mm |
180 |
|
Z axis travel |
mm |
500/700 |
|
X axis rapid traverse |
mm/min |
6000 |
|
Z axis rapid traverse |
mm/min |
8000 |
|
Tailstock quill diameter |
mm |
50 |
|
Tailstock quill taper |
- |
MT4 |
|
Tailstock quill travel |
mm |
90 |
|
Main motor power |
kw |
4 |
|
Coolant motor power |
kw |
0.09 |
|
Machine weight |
kg |
1250 |
|
Overall dimension |
mm |
1900/2100*1200*1700 |
