CK6125 CNC Lathe Machine

SPECIFICATIONS

Units

CK6125

Swing over bed

mm

230

Swing over cross slide

mm

125

Distance between centers

mm

200

Spindle bore

mm

50

Spindle bore taper

-

MT5

Spindle nose type

-

A2-5

Spindle speed steps

-

Stepless

Spindle speed range

rpm

150-2500

Turret/tool post

-

Gang type

Tool size

mm

16*16

X axis travel

mm

300

Z axis travel

mm

320

X axis rapid traverse

mm/min

8000

Z axis rapid traverse

mm/min

10000

Tailstock quill diameter

mm

45

Tailstock quill taper

-

MT4

Tailstock quill travel

mm

50

Main motor power

kw

3

Coolant motor power

kw

0.09

Machine weight

kg

850

Overall dimension

mm

1500*1100*1650
