CK61125L Heavy Duty CNC Lathe Machine
from /month
MACHINE description
|
SPECIFICATIONS |
Units |
CK61125L |
|
Swing over bed |
mm |
1250 |
|
Swing over cross slide |
mm |
850 |
|
Distance between centers |
mm |
1500/3000/4000/5000/6000/7000/8000 |
|
Guideway width |
mm |
755 |
|
Max. load capacity |
T |
6/10 |
|
Spindle bore |
mm |
130 |
|
Spindle bore taper |
- |
Metric φ160/MT6 |
|
Spindle nose type |
- |
A2-15 |
|
Spindle speed steps |
- |
VF. 4 steps |
|
Spindle speed range |
rpm |
4-300 |
|
Chuck |
mm |
φ1000 4-jaw manual |
|
Turret/tool post |
- |
Electric 4 position |
|
Tool shank size |
mm |
40*40 |
|
X axis travel |
mm |
620 |
|
Z axis travel |
mm |
1350/2850/3850/4850/5850/6850/7850 |
|
X axis rapid traverse |
mm/min |
4000 |
|
Z axis rapid traverse |
mm/min |
6000 |
|
Tailstock quill diameter |
mm |
φ160 |
|
Tailstock quill taper |
- |
MT6 |
|
Tailstock quill travel |
mm |
300 |
|
Main spindle motor |
kW |
22 |
|
Coolant pump motor |
kW |
0.25 |
|
Width * Height |
mm |
2250*2300 |
|
Length |
mm |
5000/6500/7500/8500/9500/10500/11500 |
|
Net weight |
T |
10.0/11.5/12.5/13.5/14.5/15.5/16.5 |
