BK5040 CNC Slotting Machine
from /month
MACHINE description
|
Specifications |
unit |
BK5035 |
|
Max.ramslottinglength |
mm |
350 |
|
Rammoving frequency per minute |
times/min |
0-70 |
|
Ramadjustment stroke |
mm |
200 |
|
Distance from cutter headto column surface |
mm |
625 |
|
The distance from worktable to the lower end of the slide |
mm |
680/830 |
|
Tablesize |
mm |
750x510 |
|
Tabletravel (X/Y) |
mm |
320x400 |
|
X axis motor torque |
N.M |
10 |
|
Y axis motor torque |
N.M |
15 |
|
X axis rapid traverse speed |
M/min |
5 |
|
X axis rapid traverse speed |
M/min |
5 |
|
Main motor power |
Kw |
5.5 |
|
Machine weight |
kg |
4400 |
|
Dimensions |
Mm |
2800x2400x2500 |
